ThunderHaul™ – Intelligent Electric Drive System
Powering the Future of Heavy Freight
ThunderHaul™ is EHAULA’s proprietary electric driveline and control platform—engineered to transform standard trailers and dollies into high-performance hybrid-electric assets.
By combining advanced Through-The-Road (TTR) control systems with seamless integration to existing diesel prime movers, ThunderHaul™ enables operators to cut fuel consumption, boost payload capacity, and accelerate toward zero-emission targets, without replacing equipment before their planned end of service life.
Developed and tested in Australia, ThunderHaul™ is purpose-built for the nation’s most demanding freight environments, from outback mining routes to high-productivity highway combinations.
Key Features & Inclusions
-
Integrated Through-The-Road Parallel Hybrid System
Links directly with the prime mover via dedicated CAN communication, delivering intelligent torque assistance and regenerative braking.
-
High-Performance eAxle Drivetrain
Up to 600 kW (~800 hp) and 56,900 Nm torque output via multi speed transmission.
-
Modular Design for eTrailer or eDolly Configurations
Compatible with a wide range of trailer layouts and designed for any GCM rating. Note - large combinations beyond 240 t GCM are possible but coupling upgrades might also be required.
-
Seamless Energy Integration
Fully compatible with EHAULA’s LightningVault™ battery packs through our proprietary battery swap interface.
-
Adaptive Drive Control
One-foot driving with power blending and energy recuperation during deceleration; ISO 26262-aligned safety architecture.
-
Flexible Suspension and Build Options
Air or mechanical suspension, disc or drum braking - eAxle is designed to suit the suspension of preference.
Why Choose ThunderHaul™
Cut Fuel Use by up to 40 % – reduces operating costs and emissions while maintaining productivity.
Retain Payload via PBS – extra axles offset battery weight for optimal efficiency - possible via using PBS scheme..
Plug-and-Play Integration – designed to retrofit to existing diesel fleets without major drivetrain modification.
Lower Upfront Investment – a more cost-effective transition than purchasing a full electric prime mover.
Enhanced Safety & Control – intelligent torque distribution and regenerative braking deliver smooth, stable handling.
Performance Snapshot
ThunderHaul™ ST4-245S (2025)
-
CDTL EA40000 – 2 speed
-
600 kW / 56,900 Nm
-
400 kW / 24,700 Nm
-
Quad – up tp 36,000 kg
-
Up to 245 t
-
< 8,400 kg
-
LightningVault™ Swap System
-
EHAULA Hybrid Drive Control (CAN linked)
Get in Touch
Discover how ThunderHaul™ can transform your fleet’s performance and lower your operating costs.
Contact our specialists to discuss configuration options and system integration for your operation.
